OEM Printers

We offer a full range of printers to support our C•CURE^® ID badging solution, as well as our product line of readers. Select a printer from one of the top industry ID card printer vendors to complete your access control system.

zoom

MAGICARD^®

Magicard printers offer high-quality 300 dpi images with true colors, right to the edge of the card. The HoloKote^® high security watermark ensures cards cannot be cloned. Choose from the single-sided Rio 2 model or the Tango 2 model, which produces double-sided printed ID cards.

zoom

FARGO^®

Fargo DTC400 series direct-to-card printer/encoders make issuing ID cards a remarkably simple and virtually maintenance-free process.

zoom

NISCA™

The Nisca PR5350™ offers a small footprint, 24-bit color, 256-grayscale, security lamination, and prints at the astounding speed of more than 158 cards/hour. The PR5350 offers brilliant 24-bit images printed on CR80 and CR79 cards.

Printer Comparison Chart

	Magicard Rio 2	Magicard Tango 2	Fargo DTC400	Nisca PR5350
Position	Value	Mid-range	Mid-range	High end
Print Technology	Dye-sub. 300 dpi	Dye-sub. 300 dpi	Dye-sub., 300 dpi	Dye-sub., 300 dpi
Printing	Single side	Dual side	Dual side	Dual side lamination
Print Speed	Color: 20 sec./side Mono: 6 sec.	Color: 20 sec./side Mono: 6 sec.	YMCKO 133 per hour	YMCKO More than 158 cards/hour
Color	More than 16 million	More than 16 million	16 million	More than 16 million
Card Capacity	100	100	100	100
Card Type	PVC	PVC	PVC or polyester	PVC or polyester
Supported Cards CR-100: 98.5 mm x 67 mm (3.88 in x 2.63 in) CR-90: 92 mm x 60 mm (3.63 in x 2.37in) CR-80: 85.6 mm x 54 mm (3.375 in x 2.125 in) CR-79: 83.9 mm x 52.1 mm (3.303 in x 2.051 in)	CR-80	CR-80	CR-80	CR-79 CR-80
Card Thickness	.38 mm to 1.6 mm (.015 in to .063 in)	.38 mm to 1.6 mm (.015 in to .063 in)	.51mm to .76mm (.020 in to .030 in)	.508 mm to 1.72 mm (.020 in to .050 in)
Magnetic Encoder	Optional	Optional	Dual Hi/Lo Mag. -optional	Not supported
Interface	USB, parallel, ethernet opt.	USB, parallel, ethernet opt.	USB	Parallel, SCSI II and USB V2.0
Certification	UL, CE	UL, CE	UL60950-1, CE	UL1950, CE Class B, FCC A & B
Voltage*	90 to 265 VAC	90 to 265 VAC	100 to 240 VAC	100 to 240 VAC
Dimensions (HWD)	232.5 mm x 193.5 mm x 369.5 mm (9.15 in x 7.6 in x 14.55 in), incl. hopper and stacker	232.5 mm x 193.5 mm x 471.1 mm (9.15 in x 7.6 in x 18.58 in), incl. hopper and stacker	201 mm x 464 mm x 207 mm (7.9 in x 18.28 in x 8.14 in)	421 x 271 x 331mm (16.57 in x 10.66 in x 13.03 in)
Weight	7.26 kg (16 lbs)	8.16 kg (18 lbs)	3.63 kg (8 lbs)	12.25 kg (27 lbs)

*120V power cord with printer

Qualified Printer Drivers

Item Description	Driver Version
Fargo DTC400 dual-sided printer	V2.1.3
Magicard Tango 2 printer	V5.0
Magicard Rio 2 printer	V5.0
Nisca PR5350 printer	V4.2.0

Manufacturers’ Printer Warranty Information**

Nisca	2-Year return to depot printer warranty and 1-year unlimited prints print head warranty. Nisca warranty claim phone number 800-742-2273.
Magicard	2-Year “UltraCoverPlus” return to depot warranty with free loaner printer in North America and European Union (EU). Outside North America and the EU; 1-Year return to depot printer warranty with a 1-Year or a quantity of 40,000 printed cards, whichever comes first, print head warranty. Magicard warranty claim phone number (425) 556 9708.
Fargo	1-Year return to depot printer warranty. Fargo warranty claim phone number 800-742-2273.

** The warranty information indicated is provided by its respective printer manufacturer and is not supported by Tyco Fire & Security/Software House. To process claims, please call respective manufacturer’s claim phone number.
